Tubular Conveyor
Tubular Conveyors in the Netherlands
When powders, granules and other free-flowing materials need to be moved without exposing them to the surrounding environment, a tubular conveyor offers a practical enclosed conveying option. The closed tube helps control dust and material loss while keeping the conveying path clean.
For food, pharmaceutical, chemical and industrial applications in the Netherlands, tubular vibratory conveyors can be used where hygienic and controlled material transfer is important. The system supports steady movement of materials over different distances and can be configured with multiple inlet and outlet arrangements.
With SS 304 or SS 316 construction, the conveyor is suitable for applications requiring corrosion-resistant and easy-to-clean surfaces. Capacities range from 100 kg to 5 TPH, depending on bulk density and material characteristics.
The equipment can also be configured for demanding applications involving heat-sensitive, dusty or potentially hazardous materials, subject to the required application and safety specifications. Different lengths, diameters and outlet arrangements allow the conveyor to fit into existing or new production layouts.
Tubular Conveyor Details:
- Engineered per order.
- Heat resistant.
- Explosion-proof enclosure.
- Ideal for conveying inflammable solvent powder material.
- Closed design for a dust-free environment.
- Resistance in all zones.
- Trough is in SS304 /SS316 / SS304L /SS316L with coil having special casing and protection.
- Casing is done to protect wire cable and their joints.
- Capacity range – 100 Kg to 5 TPH as per the material characteristics.
Length | 800 mm – 3500 mm |
Diameter | 200 mm-250 mm |
Capacity | 100 KG – 5 TPH (Varies According to bulk density) |
Inlet/Outlet | 1 Inlet – 1 Outlet, 2 Inlet – 1 Outlet, 1 Inlet – 2 Outlet |
Construction | SS 304 / 316 |
Applications | Food, Pharma, Chemical, Granules |
Voltage | 220 V, 50 Hz (110 V/ 60 Hz available on request) |
Didn’t find what you need? Contact us for a custom solution!
Why Choose Us
We deliver reliable, hygienic and efficient solutions trusted by leading industries. Your success is our priority.
Frequently Asked Questions
A tubular conveyor is used for enclosed conveying of powders, granules and other free-flowing bulk materials. Its closed construction helps control dust and material loss during transfer.
It can handle powders, granules, chemical materials, food ingredients, pharmaceutical materials and other free-flowing bulk products, depending on their characteristics.
The capacity ranges from approximately 100 kg to 5 TPH, depending on factors such as bulk density, material characteristics and conveyor configuration.
Yes. The enclosed tube helps contain the material and reduce dust release during conveying. This makes it suitable for applications where clean and controlled material transfer is required.
Yes. The conveyor can be customized according to the material, capacity, tube diameter, conveying length, inlet/outlet arrangement and production layout. Different construction and protection options can also be considered based on the application.
